| TECHNICAL SPECIFICATIONS |
| Model | SE25-A1 | SE35-A1 | SE50-A1 | SE75-A1 |
| Max. Load Rating | 2,250 kN | 3,150 kN | 4,500 kN | 6,750 kN |
| Pipe Range | 2-3/8" ~ 7-1/4" | 2-3/8"~ 7-1/4" | 2-3/8" ~ 9-3/4" | 2-3/8" ~ 9-3/4" |
| Dimensions(LxWxH) | 33.5" x 25.6" x 17.1"
( 850 x 650 x 450 mm ) | 42.1" x 19.7" x18.5"
( 1,070 x 500 x 470 mm ) | 44.5" x 30.7" x 21.7"
( 1,130 x 780 x 550 mm ) | 44.5" x 30.7" x 21.7"
( 1,130 x 780 x 550 mm ) |
| Hydraulic Pressure | 2,200 ~ 2,500 psi ( 15~17 MPa ) |
| Max. Open Torque | 890 ft-lb ( 1,200 N.m ) | 1,180 ft-lb ( 1,600 N.m ) |
| Max. Close Torque | 1,480 ft-lb( 2,000 N.m ) | 2,070 ft-lb ( 2,800 N.m ) |
| Max. Safety Door Open Torque | 590 ft-lb( 800 N.m ) | 1,030 ft-lb ( 1,400 N.m ) |
| Max. Safety Door Close Torque | 960 ft-lb( 1,300 N.m ) | 1,840 ft-lb ( 2,500 N.m ) |
| Controls | Auto Close, Remote Open and Interlock |
