| NOV Floor equipment parts list | |||
| Equipment | Model | Item | Description |
| Power Slips | PS-21 | 50008-20-C8D | SCREW, CAP-HEX HD DRILLED |
| Power Slips | PS-21 | 50808-N-C | WASHER, FLAT |
| Power Slips | PS-21 | 94520-1CN | PRESSURE RELIEF VALVE CARTRIDGE |
| Crown Block | 0 | 5094D065C | SHEAVE, 50″ DIA. X 10″ SHAFT X 1 3/8″ W.L., API 8C |
| Crown Block | 0 | 5171D275A | 60″ CLUSTER SHEAVE SHAFT |
| Crown Block | 0 | 5171D275C | SPACER, CLUSTER SHEAVE |
| Crown Block | 0 | 5094D011B | BUSHING, BRONZE |
| Crown Block | 0 | 5094D008A | BRACKET, SHEAVE |
| Crown Block | 0 | 5094D008B | BRACKET, SHEAVE |
| Crown Block | 0 | 42501058 | PIN, SHEAVE |
| Crown Block | 0 | 5171D123B | BLOCK, BUMPER |
| DLA | L-75 | 2191D026C | LINE GUARD |
| DLA | L-75 | 7018B386 | LOCK NUT ***SEE TEXT*** |
| DLA | L-75 | 10894887-125 | BRONZE INSERT, 1 3/8″ WL |
| Iron Roughneck | ST-80 | 18271638-001 | Accumulator AccessoryTransfer Barrier, Piston Type |
| Iron Roughneck | ST-80 | 51300-112-B | O-RING |
| Iron Roughneck | ST-80 | 30160731 | BEARING, ROLLER |
| Iron Roughneck | ST-80 | 51300-112-B | O-RING |
| Iron Roughneck | ST-80 | 30160731 | BEARING, ROLLER |
| Iron Roughneck | ST-80 | 94536-175N | CARTRIDGE,CHECK,75PSI,PHM3I |
| Iron Roughneck | ST-80 | 30160389 | ASSY,TRANSMISSION,LH |
| Iron Roughneck | ST-80 | 30160392 | ASSY, TRANSMISSION ,RH |
| Iron Roughneck | ST-80 | GREASE-CAP | GREASE FITTING CAP *OBS SEE TEXT* |
| catheads | 9015A030 | 5C01I27A | RETAINER, CABLE |
| catheads | 9015A030 | 5C01I76A | SHAFT, SHEAVE |
| catheads | 9015A030 | 5C01I79A | NUT, PISTON ROD |
| catheads | 9015A030 | 5C01I82A | NUT,RETAINING |
| catheads | 9015A030 | A9542026A | WASHER,ANCHOR POST |
| catheads | 9015A030 | 9015D079A | PLATE,HYDRAULIC CATHEAD MAX LINE PULL (S/N OF RIG |
| catheads | 9015A030 | 11051182-001 | CLAMP, HOSE |
| catheads | 9015A030 | 10292972-001 | Screw, CapHex HeadASME B18.2.10.625-11 UNC-2AL 1 i |
| catheads | 9015A030 | 11418266-001 | SCREW, SETSOCKET0.375-16 UNC-3AL 1 INMATL ALLOY ST |
| catheads | 9015A030 | A9542026B | WRENCH, ANCHOR POST WASHER HOOK |
| drawworks | D1500UEDB | 9006D323 | SPACER |
| drawworks | D1500UEDB | 9006D322 | SPACER |
| drawworks | D1500UEDB | 7006B306 | BEARING,ROLLER SPHERICAL |
| drawworks | D1500UEDB | P231000192 | AXIAL CLAMP SEAL KIT |
| drawworks | D1500UEDB | 946650 | B1363ATD PLATE SEPARATOR |
| drawworks | D1500UEDB | 947258 | A6606 TD DIAPHRAGM 30″ |
| drawworks | D1500UEDB | 9006D65 | SPACER, DWKS D1500UE |
| drawworks | D1500UEDB | 9006D78 | SPACER |
| drawworks | D1500UEDB | 9006D271 | SPACER |
| drawworks | D1500UEDB | 9006D272 | SPACER |
| drawworks | D1500UEDB | 7040B118 | MUFFLER, CLUTCH |
| drawworks | D1500UEDB | 7006B262 | BEARING, SPHERICAL ROLLER (SAME AS 7006B159) |
| drawworks | D1500UEDB | 947253 | A6599 TD INSULATOR PLATE |
| drawworks | D1500UEDB | 946650 | B1363ATD PLATE SEPARATOR |
| drawworks | D1500UEDB | A2888H | WASHER |
| drawworks | D1500UEDB | 7008B078 | PIN, PIVOT |
| drawworks | D1500UEDB | 9006D52 | SPACER |
| drawworks | D1500UEDB | 7006B169 | BEARING, SPHERICAL ROLLER |
| drawworks | D1500UEDB | 7040B010 | CYLINDER, PNEUMATIC , 4 X 12 |
| drawworks | D1500UEDB | 7040B071 | BOTTLE, 10 GALACCUMULATOR |
| drawworks | D1500UEDB | 7040B259 | VALVE, CHECK (SAME AS 7040B103) |
| drawworks | D1500UEDB | 7026B065 | VALVE, PRESSURE RELIEF |
| drawworks | D1500UEDB | 7918845 | SEAL, PACKING PISTON USE P/N 947994-562 |
| drawworks | D1500UEDB | 947272 | A6613 TD PRESSURE PLATE |
| drawworks | D1500UEDB | 9006D892 | WEAR PLATE, 1/4 SECTION *SEE TEXT* |
| drawworks | D1500UEDB | 2410021012 | PACKING, O RING POWER SWIVEL |
| drawworks | D1500UEDB | 0001-0823-47 | ASSY KEMS C1D1 MAINBRAKE VALVE |
| drawworks | D1500UEDB | 8700A545 | CAPSCREW |
| drawworks | D1500UEDB | 8700A545 | CAPSCREW |
| top drive | TDS 11 | 117603-1 | (MT)PUMP,LUBE,GEARBOX,ASSY,TDS9S |
| top drive | TDS 11 | 30156835-R75-2 | PKG,S-PIPE,RH,OUTSIDE,7500,TDS-9/11SA |
| top drive | TDS 11 | 110562-1 | TDS9S ACCUM,HYDRO-PNEU 6″ |
| top drive | TDS 11 | 18306596-003 | COVER;LOUVER, EXHAUST;TOP DRIVES;TDS-11S |
| top drive | TDS 11 | 18306596-004 | COVER;LOUVER, EXHAUST;TOP DRIVES;TDS-11S |
| top drive | TDS 11 | 114375-1 | MOTOR,HYDRAULIC,MACH,TDS9 |
| top drive | TDS 11 | 30112626 | BUSHING,SLEEVE,1.5X1.94,BRS |
| top drive | TDS 11 | 111707-2 | VALVE,BODY,MACHINING |
| top drive | TDS 11 | 50008-8-C5D | SCREW, CAP-HEX HD DRILLED |
